Descripción de Producto
Material: Brass or Zinc
2) Use For: COAXIAL CABLE
3) Plating:Gold/Nickel plated
| Temp.range: | -40~+60°C | Insulation resistance: | ≥ 1000 MΩ |
| Impedance : | 75Ω | Withstand voltage at sea level : | 750V |
| Frequency range: | 0~1GHz | Working voltage : | 170V max |
| Center conductor withdrawal force: | ≥0.49N | VSWR : | Straight ≤1.2 Angle≤1.3 |
| Contact resistance: | center conductor ≤6mΩ , outer conductor ≤1mΩ | Durability : | 500 cycles |
Specifications:
1) Temperature range: -55 - +155°C
2) Impedance: 50&Omega
3) Frequency range:DC~1GHz
4) Working voltage: 500V rms
5) Withstand voltage:1500V rms
6) Contact resistance: a) Center contact: ≤10mΩ b) Outer contact: ≤2.5mΩ
7) Insulation resistance: ≥5,000mΩ
8) VSWR: a) Straight: ≤1.22/3GHz b) Right angle: ≤1.30/3GHz
9) Durability (mating): ≥500 times
FOCAN electronic factory can be provide all kind of
F type connectors,F compression connectors for RG6, RG58 ,RG59,RG11,RG316
RF Waterproof F compression connector
F compression connector,F connector ,RG6 Compression F Connector
RF Waterproof F compression connectorn
compression tool for RG11,RG6 and RG59 coaxial cable
Specifications
F type connectors for RG6, RG58 ,RG59,RG11,RG316,PPC EX11 and EX6XL compression connectors
PCT-TRS-6,EX6WS,EX6XLWS,SFC-6,SFC-6,SPL-6/SPL-6-RTQ.EX59WS;
EX59XLWS;EX6WS;EX6XLWS;EX11N716WS;EX11RAFMWS;EX7N716WS
CMP59;CMP59Q;CMP6;CMP6Q;CMPBNC59;CMPBNC6;CMPRCA59;CMPRCA6
EX59;EX59XL;EX6;EX6XL;EX6P;EX6XLP;EX11;EX11N176;EX11RAFM;EX7;EX7N716
EXBNC6;EXBNC9167;EXBNCHE;EX59PLUS;EX59XLPLUS;EX6PLUS;EX6XLPLUS
EX59WSPLUS;EX59XLWSPLUS;EX6WSPLUS;EX6XLWSPLUS
Features:
1.Excellent insertion /withdrawal characteristics.
2.Easy installation
3. Material: Brass and nickle plating
4. OEM accept
5. Can do waterproof with O ring
6. Application: Telecom, Radios, Broad cast, Coaxial cable, CATV
